The concrete moisture meter is a measuring device for nondestructive moisture measurement on concrete and screed. Here, the spring electrodes of the concrete moisture meter are pressed onto the surface to be tested. Within seconds, the concrete moisture meter will show the moisture content to the operator.
Application
This moisture meter is designed for testing moisture levels in wood and building materials. Combined the microcontroller technique and integrated characteristics for 4 material groups Increase the accuracy of measurements. It is widely used for measuring the moisture level in a rough professional environment.
Features
- Use on woods, bamboo, paper, wood fibre articles, and building materials
- Big LCD display with backlight
- Replaceable electrode pins
- 2-in-1 Digital LCD readout and analogue bar graph
- Simultaneous measurement and display of moisture & temperature readings
- Materials selection measurements
- MAX/MIN/DATA Hold
- Auto power off
Specifications:
| Electrode | 1Omm(replaceable) |
| Moisture Range | Wood: 5–70%RH |
| Building materials: 0.1-2.4%RH | |
| Temperature Range | -20-70’C/-4-158’F |
| Moisture Accuracy | Wood:5-30%: +% 30-60%: +2% 60-70%: +4% |
| Other materials:+0.5 % | |
| Temperature Accuracy | -20-70 C/-4-158 T: +1.5’C/2.7F |
| Auto Power Off | Meter shuts off automatically after 120 seconds of inactivity |
| Power Supply | One 9V battery |
| Operating Temperature | 0-50’C/32-122 F |
| Operating Humidity | 0-85 %RH |
Operating Instruction:
7.1 Open the battery cover and install a 9V battery (battery type: 006P or NEDA1604 or IEC6F22) in the Battery Compartment.
Remove the protective cap to expose the electrode pins, carefully push the electrode pins as far as possible into the materials under test. Take several readings in several locations on the material for the best representation of the amount of moisture present. The measured values will be displayed on the LCD
