Name: Yearn Tension Meter ZF2
Availability: InStock

Yearn Tension Meter ZF2

65,000.00৳

Price	:	65000 BDT
Warranty Period	:	1 year
Model	:	ZF2
Stock	:	Available
Origin	:	Germany
Discount	:	No
Brand	:	Schmidt
Product	:	Available
Delivery Charge	:	200 BDT

Description

Special Features

The analog display of tension meter ZF2 shows changing and fluctuating tensions fast and enables an optimal process adjustment

Filament guide and roller shifting mechanism ensure easy acquisition of the running material

Large, easy to read scale (54 mm Ø)

Light weight

Standard Features

Everything in operator’s view:
– the guide rollers
– the measured material
– the readings

Ball-bearing mounted, V-grooved guide rollers

Each instrument is individually calibrated for highest accuracy

Housing made of high-strength plastic

Certificate of Compliance with the order 2.1 according DIN EN 10204 is included

Optionally available: Inspection Certificate 3.1 according DIN EN 10204 with calibration report

Calibration to customized material:
If process material differs significantly from the SCHMIDT calibration material in diameter, rigidity or shape, special calibration using customer supplied samples is recommended. For this purpose a material sample of about 5 m should be supplied.

Specifications

Calibration:	According to SCHMIDT factory procedure
Accuracy:	±1 % full scale or ±1 graduation on scale
Scale diameter:	54 mm
Temperature range:	10 – 45 ºC
Air humidity:	85 % RH, max.
Housing material:	Plastic (POM)
Dimensions:	See dimensions
Weight, net (gross):	Approx. 200 g (Approx. 600 g)

Specifications subject to change without notice!

Scales

SCHMIDT scales are manufactured according to the most stringent quality requirements. Printed scales are not used. Instead, each scale is individually marked for the instrument involved. This ensures highest quality. Our special procedure makes it possible to provide tension meter ZF2

calibrated to custom supplied material
fine tuned to a specific tension range
other units of measure such as g

: ZF2 – 5

: ZF2 – 10

: ZF2 – 12

: ZF2 – 20

: ZF2 – 30

: ZF2 – 50

: ZF2 – 100
